Proto 16 Blade Overhead Valve Feeler Gauge Set J000R-SBD

Proto's 16-Blade Overhead Valve Feeler Gauge Set is engineered specifically for setting overhead valves with enhanced safety and access. The key feature of this set is that the 1/2" wide blades are offset at a right angle (bent) to effectively protect the user's hands from a hot manifold during the valve setting process. The set includes 16 imperial sizes: .009", .010", .011", .014", .015", .016", .017", .018", .019", .020", .021", .023", .024", .025", .026", and .027". For maximum utility, every blade is clearly etched with both its decimal size and the corresponding metric equivalent. The overall tool has a length of approximately 7-2/7 inches, a width of 3/5 inch, and a height of 1-1/9 inches.
Key Features
- Specialized Application: Designed specifically for accurately setting overhead valves.
- Safety Feature: Blades are offset at a right angle to protect hands from hot manifolds.
- 16 Blade Sizes: Includes a range from .009" up to .027".
- Comprehensive Sizes: Features .009", .010", .011", .014", .015", .016", .017", .018", .019", .020", .021", .023", .024", .025", .026", and .027".
- Dual-Etched: Blades are etched with both the decimal size and metric equivalent.
- Blade Width: All blades are 1/2" wide.
- Long Reach: Product length is approximately 7-2/7 inches.
