1/4" Anchor Shackle 5410405-APX

Campbell's 1/4" Anchor Shackle with Screw Pin is constructed from drop-forged carbon steel and painted blue for easy identification. The shackle body is self-colored, and the C-419-S series meets the design requirements of Federal Specification RR-C-271, Type IVA, Grade A, Class 2. Each shackle is permanently marked with the working load limit, size, manufacturer’s name, date code, and “USA” for full traceability. Designed for strength and durability, these shackles are statistically tested for impact resistance, tensile strength, hardness, ductility, and fatigue. The 419 Series also meets or exceeds all manufacturing requirements of ASME B30.26 “Rigging Hardware,” including specifications for material ductility, design factor, identification, and effective temperature range. Shackles can be proof-tested upon request, in accordance with ASME guidelines. Featuring a 6 to 1 design factor, the pins and bolts are heat-treated alloy steel for added reliability. DO NOT EXCEED THE WORKING LOAD LIMIT.
Key Features
- Shackle Bodies Are Drop-Forged Carbon Steel
- Self Colored (Painted Blue)
- C-419-S Shackles Meet the Design
Requirements of Federal Specification RR-C-271, Type IVA, Grade A, Class 2
- Working Load Limit, Size, Manufacture Name, Date Code and USA Permanently Marked on Each Shackle
- Statistically Tested for Impact Resistance, Tensile Strength, Hardness, Ductility and Fatigue
- 419 Series Shackles Meet or Exceed All Manufacturing Requirements of the ASME B30.26 ”Rigging Hardware”. These Include the Material Ductility Requirement (Section 26-1.1.2), the Design Factor Requirement (Section 26.1.2), the Identification Requirement (Section 26-1.5.1), and the Effective Temperature Range (Section 26-1.6.1). The Shackles Can Be Proof Tested in Accordance with Section 26-1.4 Upon Request
- 6 to 1 Design Factor
- Pins and Bolts Are Heat-Treated and Made of Alloy Steel
- DO NOT EXCEED THE WORKING LOAD LIMIT
